2244L 21.5" Open Frame Touchscreen (Discontinued August 2013)
How to Buy

Overview

The Elo Touch Solutions 2244L open-frame LCD touchmonitor with its slim design and narrow outside dimensions gives kiosk integrators an edge in developing the most aesthetically pleasing products. Wide-aspect displays like the Elo 2244L are easier to use and incorporate than traditional open-frame touchmonitors. Wide-screen format displays allow extra content on the screen and are quickly becoming preferred in casino gaming, amusement and entertainment settings and are increasingly popular in public venue environments due to the high-definition cinematic-like experience. Typical applications for the 2244L include: gaming and amusement, information kiosks and self-service, as well as interactive digital signage applications.

State-of-the-art LED backlighting used in the 2244L makes the panel thinner overall as the cold cathode fluorescent lights (CCFL) are replaced with LED lights. LED lights also take less electricity to operate and generate less heat. This leads to the slimmer dimensions of the 2244L that facilitate OEMs and system integrators the flexibility to design aesthetically pleasing and stylish kiosks.

Available with IntelliTouch, IntelliTouch Plus, standard bezel surface acoustic wave, as well as IntelliTouch Zero-Bezel SAW and IntelliTouch Pro projected capacitive touchscreen technology for a true flat look,, the 2244L provides stable "drift-free" operation with outstanding image clarity, resolution, and light transmission - for an accurate touch response and vivid images. Projected capacitive provides a durable, zero-bezel, glass-to-edge surface with multi-touch, while surface acoustic wave is the optical standard of touch and widely used in kiosk and gaming applications. Both are pure glass constructions to deliver a clear, bright and long-lasting performance and it also makes the touchscreens scratch-resistant. It is nearly impossible to physically "wear out" these touchscreens.

Features

  • Slimmer dimensions enables thinner, artistic enclosure designs
  • Multi-touch, dual-touch and single touch options available
  • High definition LCD display offers ultimate HD interactivity, clarity and resolution
  • Portrait and landscape mode possible
  • IntelliTouch Pro projected capacitive passes ball-drop impact testing to IK07 and UL 60950 standards and offers four touch points (HID)
  • Viewing angle of 178°(h) × 178°(v), wider than most 22” touchmonitors, allows colors to remain sharp and graphics to retain their integrity in both portrait and landscape modes
  • 16:9 aspect ratio and bright 250 nits panel for a larger display surface and bright vivid images
  • LED backlighting allows for state-of-the-art slim design while reducing power consumption
  • Optimized for use in high-traffic environments
  • Three year warranty

Specifications

  • Technical

    Part Number(s)

    APR (Antiglare, Worldwide) - E738068

    Enclosure Color

    Black

    Touch Technology & Capacity

    Acoustic Pulse Recognition - Single Touch

    Touch Interface

    USB

    Diagonal Size

    21.5'' diagonal, Active matrix TFT LCD (LED)

    On Screen Display

    Controls: Menu, Up, Down, Select
    Settings: Brightness, Contrast, Clock, Phase, H-position, V-position, Auto-Adjust, Aspect Ratio, Sharpness, Color Temperature, OSD Timeout, OSD Language, OSD H-Position, OSD V-Position, Recall Defaults, Video Source
    Languages: English, French, Italian, German, Spanish, Simplified Chinese, Traditional Chinese, Japanese
    Lockouts: OSD, Power

    Accessible through switches on the unit's tethered OSD Control Box.

    Aspect Ratio

    16:9

    Active Area

    18.7" x 10.5" / 475 mm x 267 mm

    Resolution

    1920x1080

    Other Supported Resolutions

    640x480 60Hz
    720x576 50Hz
    800x600 56, 60Hz
    1024x768 60Hz
    1280x720 50, 0Hz
    1280x960 60Hz
    1280x1024 60Hz
    1366x768 60Hz
    1440x900 60Hz
    1680x1050 60Hz
    1920x1080 50, 60Hz

    Viewing Angle

    Horizontal: ±89° or 178° total / Vertical: ±89° or 178° total

    Number of Colors

    16.7 million

    Brightness (typical)

    LCD panel: 250 nits

    Response Time-total (typical)

    14 msec

    Contrast Ratio

    1000:1

    Input Video Format

    Analog VGA, DVI-D

    Input Video Signal Connector

    Analog VGA on Female DE-15 connector; Digital on Female DVI-D connector

    Power Supply

    External DC - Optional power brick (sold separately)

    Input power connector (Monitor)

    Type: DC Barrel Jack
    Barrel inner diameter: 6.4mm (+/- 0.3mm)
    Pin outer diameter: 2.0mm (+0.0 -0.1mm)
    Input voltage range: +12VDC ±5%

    Power connector (Power brick)

    Type: IEC 60320 C14
    Adapter input voltage range: 100-240VAC, 50/60Hz

    Input Voltage

    +12VDC ±5%

    Input Connector

    DC Barrel Jack

    Input Frequency

    Horizontal: 31.5-80 kHz
    Vertical: 50-75 Hz

    Power Consumption (Typical)

    ON (monitor only): 26W
    ON (monitor + AC/DC adapter at 230V/50Hz): 39W
    SLEEP (monitor + AC/DC adapter at 230V/50Hz): 1.5W
    OFF (monitor + AC/DC adapter at 230V/50Hz): 1.0W

    Dimensions

    Please reference the dimensional drawing

    Shipping Box Dimensions

    7.87" x 16.93" x 24.41" / 200 mm x 430 mm x 620 mm

    Weight (Unpackaged)

    10.6 lbs / 4.8 kg

    Weight (Packaged)

    15.3 lbs / 7.0 kg

    Operating Temperature

    0°C to 40°C / 32°F to 104°F

    Storage Temperature

    -20°C to 60°C / -4°F to 140°F

    Humidity

    Operating: 20%-80% Storage: 10%-90%

    MTBF

    50,000 hours demonstrated

    Warranty

    3-year

    Regulatory approvals and declarations

    S-Mark, C-Tick, cUL, IC, CCC, CE, VCCI, KCC, Mexico CoC, Taiwan BSMI, UL, FCC, International CB
    RoHS, China RoHS, WEEE, IMERC

    Mounting Options

    VESA 4-hole 100mm mounting interface on rear of unit
    2-hole mounting interface on all 4 sides

    See dimensional drawings for details

    Options / Peripherals / Upgrades

    Remote OSD (RJ45) - Elo P/N: E483757
    Replacement Cable Kit - Elo P/N: E378229
    North America power adapter and cable kit - Elo P/N: E005277
    European & Korea power adapter and cable kit - Elo P/N: E571601
    UK power adapter and cable kit - Elo P/N: E180092
    China power adapter and cable kit - Elo P/N: E558862
    Taiwan power adapter and cable kit - Elo P/N: E818655
    Japan power adapter and cable kit - Elo P/N: E182546
    Argentina power adapter and cable kit - Elo P/N: E887099
    IntelliTouch Stylus Pen - Elo P/N: D82064-000
    Elo 22-inch Rack-mount Bracket - Elo P/N: E462672 (See Mounting Options Spec for Compatibility)
    Elo 22-inch Wide Front-mount Bezel - Elo P/N: E668194 (See Mounting Options Spec for Compatibility)
    Elo 22-inch – Wide L Bracket Kit – Elo P/N: E530432

    Optional IntelliTouch Stylus Pen

    Stylus pen with rubber tip, designed specifically for use with IntelliTouch surface wave touch technology. Part number D82064-000, available at additional cost
