TH10 Trigger Handle

Specifications

• Technical

  ---

  Part Number(s)

  E393015

  Enclosure Color

  Black

  Compatibility

  M50 Mobile Computer

  I/O Ports

  USB-C

  Dimensions

  7.52" x 3.62" x 5.04" / 191 mm x 92 mm x 128 mm

  Shipping Box Dimensions

  8.07" x 6.22" x 5.28" / 205 mm x 158 mm x 134 mm

  Weight (Unpackaged)

  0.38 lbs / 0.18 kg

  Weight (Packaged)

  1.50 lbs / 0.68 kg

  Operating Temperature

  0°C to 50°C / 32°F to 122°F

  Storage Temperature

  -30°C to 60°C / -22°F to 140°F

  Humidity

  Operating: 20% - 80%
  Storage: 10% - 95%

  ESD

  Class C: 8KV Contact, 15KV Air

  Regulatory approvals and declarations

  UL, FCC (US) - Class B
  cUL, IC (Canada)
  CB (International safety)
  CE (Europe) - Class B
  VCCI (Japan)
  RCM (Australia)
  China RoHS

  MTBF

  50,000 hours demonstrated

  Warranty

  1-year

  What's in the Box

  TH10 Trigger Handle
  QIG
  Power Adapter
  US/EU/UK adapter plugs
