VFD Customer Display

Specifications

• Technical

  ---

  Part Number(s)

  Black - E001003
  White (MTO) - E454697

  Enclosure Color

  Black

  Display Type

  Vacuum fluorescent display (VFD)

  Display Color

  Green

  Brightness (typical)

  500-1000 cd/m2

  Characters Available

  95 alphanumeric & 32 international characters

  Dot Size (X x Y)

  0.86 x 1.2mm

  Font Size (W x H)

  5.5 x 10.5

  Character Number

  20 characters by 2 lines

  Power Supply

  5.0 VDC

  Power Consumption (Typical)

  2.0 W

  Interface

  USB/RS-232 (with baud rates select from 9600 or 19200 bps)

  Viewing Angle

  Max. 90°

  Panel Dimension

  220mm x 50mm x87mm

  Number of Colors

  16.7 million

  Supported Command Types

  UlTIMATE
  LD220
  EPSON POS D101
  AEDEX
  UTC/S
  UTC/P,
  ADM788
  DSP800
  CD5220
  EMAX
  LOGIC CONTROL

  Language Support

  US English, Int'l English, Bosnia, Croatian, Czech, Danish, Dutch, Estonian, Faroese, Finnish, Flemish, French, Fr Canadian, German, Greek, Hebrew, Hungarian, Icelandic, Indonesian, Irish, Italian, Katakana, Latvian, Lithuanian, Norwegian, Polish, Portuguese, Romanian, Russian, Slovene, Slovak, Spanish, Swedish

  MTBF

  30,000 hours demonstrated

  Supported Operating Systems

  Windows POSReady 7 32-bit
  Windows Embedded Pro 7 32-bit
  Windows Embedded Pro 7 64-bit
  Windows Industry Embedded Pro 8.1 32-bit
  Windows Industry Embedded Pro 8.1 64-bit
  Windows 10 IoT Enterprise 201x 64-bit
  Android 4.4.2

  Weight (Unpackaged)

  0.7 lbs / 0.32 kg

  Weight (Packaged)

  1.05 lbs / 0.48 kg

  Warranty

  3-year
