Completely redesigned
I‑Series 3 with Intel.
Brilliant and beautiful,
interactive platform.
10-touch
TouchPro PCAP
Fanless, IP54
rated design
HD IPS
Touchscreen
Easy to clean
edge-to-edge glass
50,000
MTBF
Modular design.
Endless versatility.
Available in sizes ranging from 15 to 24 inches, including with
and without stand options, you can easily configure the I‑Series
to fit the needs of your business - from signage and point-of-sale
to self-service, automation controls and more.
Universal VESA Mount
Conveniently mount the
I‑Series with the built‑in
VESA mount.
Expand with Edge Connect
Seamlessly attach a variety
of peripherals to the edge of
the touchscreen.
Reliable, security
and performance.
Built with the reliability-tested performance and security of Intel 12th
Generation processors, integrated Trusted Platform Modules, Intel
vPro™ and the Windows 10 operating system, the I‑Series 3 delivers
the dependability businesses need.
Enhanced connectivity
for all your accessories.
- USB-C full featured
- Gigabit LAN
- Powered RJ50 Serial
- 24V Powered USB
- 2x 12V Powered USB
- 12V/24V Cash Drawer
- 4x USB 3.0
- 4x Micro-USB Edge Connect
- WiFi & Bluetooth 5.3
Support
for Linux.
For added flexibility, the I‑Series 3 offers no
OS models, all pretested with Linux SuSE,
Ubuntu and Red Hat operating systems.
Elo Bridge
Bridge the gap between
Windows and Android.
Transitioning to Android in the future? Elo Bridge
is the perfect solution. Simply choose the Elo
Windows device that fits your needs today, and
when you are ready to transition to Android, you
can use Elo Bridge to migrate your fleet of devices.
Get peace of mind
with EloCare.SM
- Advance Unit Replacement
- Extended Warranty
- Professional Services
Specifications
-
Technical
Part Number(s)
Celeron, Win10, 8GB RAM, 128GB SSD, Anti-glare, With Stand - E708554
Celeron, No OS, 8GB RAM, 128GB SSD, Anti-glare, With Stand - E708361
i3, Win10, 8GB RAM, 128GB SSD, Anti-glare, With Stand - E708953
i3, No OS, 8GB RAM, 128GB SSD, Anti-glare, With Stand - E708749
i5, Win10, 8GB RAM, 128GB SSD, Anti-glare, With Stand - E709349
i5, Win10, 16GB RAM, 256GB SSD, Anti-glare, With Stand - E869447
i5, No OS, 8GB RAM, 128GB SSD, Anti-glare, With Stand - E709150
i7, Win10, 16GB RAM, 256GB SSD, Anti-glare, With Stand - E709726
i7, No OS, 16GB RAM, 256GB SSD, Anti-glare, With Stand - E709537Enclosure Color
Black
Touch Technology & Capacity
PCAP (TouchPro® Projected Capacitive) - 10 Touch
Processor
Celeron: Intel Celeron Processor 7305L (8M Smart Cache, up to 1.10 GHz)
i3: Intel Core i3-1215UL Processor (10M Smart Cache, up to 4.40 GHz by Intel Turbo Boost Technology 2.0)
i5: Intel Core i5-1245UL Processor (12M Smart Cache, up to 4.40 GHz by Intel Turbo Boost Technology 2.0) with Intel vPro Support
i7: Intel Core i7-1265UL Processor (12M Smart Cache, up to 4.80 GHz by Intel Turbo Boost Technology 2.0) with Intel vPro SupportGraphics
Intel UHD Graphics
For i5 & i7 Models: Intel Iris Xe Graphics eligible: to use the Intel Iris Xe Graphics, the system must be populated with 128-bit (dual channel) memory. Otherwise, use the Intel UHD Graphics.BIOS
AMI
Memory (RAM)
Celeron & i3: 8GB 4800MHz DDR5 SO-DIMM on 1 of 2 slots (Expandable to 64GB maximum on 2 slots)
i5 & i7: 16GB 4800MHz DDR5 SO-DIMM on 1 of 2 slots (Expandable to 64GB maximum on 2 slots)
NOTE: Maximum memory using 2 slots. Expandable up to 64GB maximum, SO-DIMM DDR5-4800. Check brand of the memory included in your unit before purchasing the memory kit.Storage
128GB M.2 PCIe (NVMe) SSD 80 TBW
256GB M.2 PCIe (NVMe) SSD 160 TBW
GB equals one billion bytes when referring to storage capacity. Accessible capacity may be less.TPM
2.0
Active Management Technology (AMT)
Celeron & i3: N/A
i5 & i7: Intel Active Management TechnologyDiagonal Size
17'' diagonal, Active matrix TFT LCD (LED)
Aspect Ratio
5:4
Active Area
13.3" x 10.64" / 337.9 mm x 270.3 mm
Resolution
1280 x 1024 @ 60Hz
Number of Colors
16.7 million
Brightness (typical)
LCD panel: 250 nits
TouchPro PCAP: 212.5 nitsResponse Time-total (typical)
25 msec
Contrast Ratio
1000:1
Viewing Angle
Horizontal: ±85° or 170° total / Vertical: ±80° or 160° total
I/O Ports
1x RJ45 LAN (Gigabit) Port
4x USB 3.0 Ports
4x Micro USB 2.0 Ports for Elo Edge Connect peripherals
1x 24V Powered USB Port
2x 12V Powered USB Ports
1x RJ50 Powered Serial Port
1x 12V/24V Cash Drawer Port (EPSON Pinout, 24V default; selectable by BIOS setting)
1x Full-function USB-C Port (Power up to 27W, USB 3.0, Display Port, Additional Video Out)
1x Audio Port (3.5 mm headset jack)Wireless
802.11 a/b/g/n/ac/ax 2.4GHz, 5GHz and 6GHz
Bluetooth
Bluetooth 5.3
Speakers
2 x 2W internal speakers
OS
No OS
Windows 10 IoT Enterprise LTSC 64-bitLanguages
Windows 10 - 36 Language groups
Power Supply
External 24VDC universal-type power supply brick
AC input voltage: 100-240 VAC
Input frequency: 50-60 Hz
Maximum output power: 180WPower Consumption (Typical)
Without Peripherals*
On Celeron: 33W
On i3: 47W
On i5: 50W
On i7: 54W
Sleep: < 5W
Off: < 0.5W
*Condition for i7 models with 16GB DIMM/256GB SSD, others with 8GB DIMM/128GB SSDDimensions
15.49" x 14.61" x 8.09" / 393.4 mm x 371.2 mm x 205.6 mm
Shipping Box Dimensions
20.8" x 21.2" x 12.4" / 529 mm x 539 mm x 315 mm
Weight (Unpackaged)
21.16 lbs / 9.6 kg
Weight (Packaged)
27.34 lbs / 12.4 kg
Operating Temperature
0°C to 35°C / 32°F to 95°F
Note: the thermal report pass airflow 0.5m/s condition. For non-OS SKUs, recommend using the Elo optimize TDP tool for better performance.Storage Temperature
-20°C to 60°C / -4°F to 140°F
Humidity
Operating: 20% to 80%
Storage: 5% to 95% (38.7°C max wet bulb temperature)Energy Star
Energy Star 8.0 certified configurations available
Regulatory approvals and declarations
Canada cUL, IC
United States UL, FCC
Germany TUV
Europe CE
Australia RCM
United Kingdom UKCA
International CB
Argentina S-Mark
Brazil ANATEL
Japan VCCI, MIC
China CCC, SRRC
Mexico NOM
RoHS CoC
New Zealand R-NZReal-Time Clock
CR2450 lithium metal battery
MTBF
50,000 hours demonstrated
Mounting Options
100mm VESA mount
Warranty
3-year
Extended Service Options
4 year warranty coverage - Elo P/N: E819598
5 year warranty coverage - Elo P/N: E819795
3 year warranty coverage + AUR - Elo P/N: E820186
4 year warranty coverage + AUR - Elo P/N: E820388
5 year warranty coverage + AUR - Elo P/N: E820582Ingress Protection
IP54
Sealability
Touchscreen sealed to sub-bezel
Touchscreen sealed to LCDPower Cables
North American and European power cables included
Other Features
Serviceable internal components
Kensington lockWhat's in the Box
I-Series
North America Power Cord
European Power Cord
Power Adapter – 180W
Cable RJ-50 to DB-9
Quick Installation Guide (QIG)
Cable tie
CFD mounting screw
VESA mounting screw
VESA cover
VESA cover mounting screwUpgrade Options
8GB 5600MHz DDR5 SO-DIMM – Elo P/N: E466053
16GB 5600MHz DDR5 SO-DIMM – Elo P/N: E466237
32GB 5600MHz DDR5 SO-DIMM – Elo P/N: E466430
M.2 PCIe (NVMe) 128GB SSD – Elo P/N: E466613
M.2 PCIe (NVMe) 256GB SSD – Elo P/N: E466803
Changing SO-DIMM or SSD requires opening the back cover. Special care must be taken when removing and replacing the back cover to prevent losing the IP rating or possibly damaging the touch computer. Please contact Elo technical support or product managOptional Peripherals
Magnetic Stripe Reader (MSR) – Elo P/N: E001002
Fingerprint Scanner – Elo P/N: E134286
Customer Display (2x20 VFD) – Elo P/N: E001003
2D Barcode Scanner (Black - SE4720) – Elo P/N: E384627
2D Barcode Scanner (Black - SE4107) – Elo P/N: E245047
EMV Cradle for MagTek eDynamo - Elo P/N: E375343
EMV Cradle for Ingenico RP457c (with Audio Jack, BT and USB) - Elo P/N: E586981
EMV Cradle for Ingenico RP457c (with BT and USB) - Elo P/N: E710930
Status Light (Micro-USB Connectivity) - Elo P/N: E644767
3D Camera - Elo P/N: E134699
Webcam - Elo P/N: E201494
RFID - Elo P/N: E673037
Elo Edge Connect™ Speaker Bar (Black) - Elo P/N: E894719
Elo Edge Connect™ Speaker Bar (White) - Elo P/N: E133780Stands, Mounts & Kits
Wall Mount Kit (75mm or 100mm VESA) – Elo P/N: E143088
Tabletop Stand for 17"/21.5" Displays - Elo P/N: E467190
Shelf Mount Bracket (75mm or 100mm VESA) - Elo P/N: E043382
Slim Self-Service Countertop Stand (75mm or 100mm VESA) - Elo P/N: E514693
Slim Self-Service Floor Stand (75mm or 100mm VESA) - Elo P/N: E514881 + E515260
Power Brick Kit, 24V 180W - Elo P/N: E845269
1002L - Elo P/N: E155834
1002L - Elo P/N: E324341
1302L - Elo P/N: E683595
Elo 2ft authorized USB-C cable - Elo P/N: E969524
Elo 6ft authorized USB-C cable – Elo P/N: E710364
Wallaby™ Self-Service Countertop Stand (75mm or 100mm VESA) - Elo P/N: E421137
Wallaby™ Self-Service Floor Stand (75mm or 100mm VESA) - Elo P/N: E421325 + E797162
